Specification |
LZ-8/560 |
|
Capstan Dia. |
560mm |
|
Draw No. |
8 |
|
Inlet Diameter |
Φ5.5mm |
|
Outlet Diameter |
Φ2.2mm |
|
Max. Compres. Ratio |
80% |
|
Max. speed |
10m/s |
|
Motor power |
30KWx8 |
|
Die size |
Φ40mm×30 |
|
Machine direction |
from left to right |
|
Payoff |
from pre-processing line |
|
Takeup |
800 Spooler |
|
Die box |
compressed lubricant die box |
|
Capstan cooling |
water cooling + fan cooling |
|
Die box cooling |
water cooling |
|
Tension control |
included |
|
Safty Device |
included |
|
Braking |
pnumatic braking |
|
Electrical system |
PROFIBUS-DP |
|
PLC |
Siemens 300PLC |
|
Touch screen |
Siemens 5.7' |
|
Motor |
Henda |
|
Low voltage product |
Schneider |
|
Inverter |
Innovance |
|
Sensor |
Lanbao |
